AWARD BO-1624 DIA 1 SH 2.00 LOC 6.00 OAL 9.50 End Mill Taper Flute HSS Uncoated Single End Square Sharp

Need Assistance or Service? Please call 262-251-4020

Manufacturer: AWARD
SKU: AWABO-1624
Delivery date: 3-5 days
$457.69

Cutting Edge Definition

High speed steels (often abbreviated HSS) are ferrous based alloys of the Fe–C–X multicomponent system where X represents a group of alloying elements comprising mainly Cr, W or Mo, V, and Co. These steels are mainly used for cutting tools, since they are characterized by their capacity to retain a high level of hardness while cutting metals at high speed. Generally, the X component is present in excess of 7%, along with more than 0.60% carbon.

Products specifications
Attribute name Attribute value
General Product Information
Application Copy Milling, Face Milling, Profile Milling, Taper Side Milling
Shipping State Michigan
Package Size 1
Made In USA Yes
Performance Rating General Performance
Dimensional Specifications
Cut Rating <40HRC Steel, Aluminum, Ductile Iron, Gray Iron
Taper Flute Yes
Cutter Dia 1.0000 25.40MM
Cut Dia Max 2.0499 52.07MM
Machine Side Connection Type Cylindrical
Inch/Metric Inch
Taper Angle 5.0°
Single/Double End Single End
Dimension Description 1.000 x 2.000 x 6.000 x 9.500
Overall Len 9.5000 241.30MM
Cutter Style Taper Flute Finisher
Helix Angle 30°
Machine Side Connection Size 2.0000 50.80MM
Tool Material High Speed Steel
Shank/Pilot Dia 2.0000 50.80MM - 2
Flutes/Inserts 4
Length Of Cut 6.0000 152.40MM
Length Type Standard
End Of Tool Shape Square
Cutting & Machining Properties
Center Cutting No
Cutting Edge Mat HSS
Coolant Thru No
Industry-Specific Applications
Aerospace Yes
Mold Yes
Automotive Yes
Job Shop Yes
Agricultural YES
Energy Yes
