AWARD BKK-1624TIN DIA 1 SH 1.00 LOC 6.00 OAL 8.50 End Mill Taper Flute HSS TiN Single End Square Sharp

Need Assistance or Service? Please call 262-251-4020

Manufacturer: AWARD
SKU: AWABKK-1624TIN
Delivery date: 3-5 days
$219.73

Cutting Edge Definition

High speed steels (often abbreviated HSS) are ferrous based alloys of the Fe–C–X multicomponent system where X represents a group of alloying elements comprising mainly Cr, W or Mo, V, and Co. These steels are mainly used for cutting tools, since they are characterized by their capacity to retain a high level of hardness while cutting metals at high speed. Generally, the X component is present in excess of 7%, along with more than 0.60% carbon.

Grade and Coating Description

Titanium nitride (TiN) coating is wear resistant, inert & reduces friction. Used on cutting tools punches etc improving tool life 2-10x over uncoated tools

Products specifications
Attribute name Attribute value
General Product Information
Made In USA Yes
Application Profile Milling, Taper Side Milling, Copy Milling, Face Milling
Coating TiN
Performance Rating General Performance
Shipping State Michigan
Package Size 1
Dimensional Specifications
Tool Material High Speed Steel
Flutes/Inserts 4
Length Of Cut 6.0000 152.40MM
Length Type Standard
Overall Len 8.5000 215.90MM
Cutter Style Taper Flute Finisher
Helix Angle 30°
Taper Angle 0.5°
Cutter Dia 1.0000 25.40MM
Cut Rating <40HRC Steel, Aluminum, Ductile Iron, Gray Iron
Taper Flute Yes
Shank/Pilot Dia 1.0000 25.40MM
End Of Tool Shape Square
Machine Side Connection Type Cylindrical
Machine Side Connection Size 1.0000 25.40MM
Inch/Metric Inch
Dimension Description 1.000 x 1.000 x 6.000 x 8.500
Cut Dia Max 1.1047 28.06MM
Single/Double End Single End
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat HSS
Center Cutting No
Industry-Specific Applications
Automotive Yes
Job Shop Yes
Aerospace Yes
Mold Yes
Agricultural YES
Energy Yes
