  • AB ToolS Shell Arbor 200 Parallelogram 90.0°, Face Mill Shell Arbor 0.5000 Positive 2.0000 50.80MM Cutter Dia
Picture of AB ToolS Shell Arbor 200 Parallelogram 90.0°, Face Mill Shell Arbor 0.5000 Positive 2.0000 50.80MM Cutter Dia

AB ToolS Shell Arbor 200 Parallelogram 90.0°, Face Mill Shell Arbor 0.5000 Positive 2.0000 50.80MM Cutter Dia

ANSI: SHELL 200

ISO: SHELL 200

Need Assistance or Service? Please call 262-251-4020

Manufacturer: AB TOOLS
SKU: ABTSHELL 200
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Features And Benefits

Shell Shear-Hogs

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Pocket Milling, Slot Milling, Face Milling, Ramp Milling, Side Milling
Insert Type Positive
Package Size 1
Insert Application Semi Finishing, Roughing
Made In USA Yes
Shipping State California
Dimensional Specifications
Tool Material Steel
Flutes/Inserts 3
Machine Side Connection Size 0.5000 12.70MM
Overall Len 1.2500 31.75MM
Insert Size Ic 43
Cutter Dia 2.0000 50.80MM
Depth Of Cut Max 0.3750
Machine Side Connection Type Face Mill/Shell Mill
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Extractor T8
Insert Style AD
Fasteners & Connectors
Insert Screw 3.5MM SHC
